Digital Advertising Totem
1. CPU 64-bit 4 cores, main frequency 1.5GHZ, 1GB DDR and 8 GB eMMC RJ45.
2. Internet: 1*10/100M Ethernet ; RJ45.
3. WIFI: Wi-Fi with antenna, 802.11 1×1 BGN+BT.
4. Board Interfaces: USBX2,TF Reader X1,RJ45 X1,HDMI-INX1 (option, if needs).
5. PC Built-in Option: Usually Intel J1900/ I3 /I5 CPU, 4G memory, 120G SSD, Wi-Fi (Options: Chipset Intel HM76/ H81/H110 ).
6. Infrared technology Infrared mutlit touch, finger and gloved hand, or any opaque objects.
Description
Arotouch Digital Advertising Totem is a floor-standing commercial display designed to present advertisements, promotions, videos, product information, and business messages in high-traffic indoor locations.
The vertical design makes the screen easy to notice while using a compact floor-standing format. It is suitable for airports, hotel lobbies, restaurants, cafes, retail stores, shopping malls, hospitals, banks, and corporate offices.
High-Visibility Advertising Display
The Digital Advertising Totem gives businesses a dedicated digital space for promotional content.
Instead of relying on printed posters, businesses can display videos, images, special offers, product information, announcements, and other marketing content on one digital screen.
The display can be positioned near entrances, reception desks, waiting areas, corridors, and customer service points.
Free CMS System for Advertising Content
Arotouch provides a Free CMS System with this digital signage solution.
The CMS allows businesses to manage digital advertising content more conveniently. Images, videos, promotions, and information can be prepared for display according to different business needs.
WiFi and RJ45 Ethernet are available for network connectivity. This makes the display suitable for connected commercial signage projects.
Full HD Display with Optional 4K
The standard configuration uses 1920×1080 Full HD resolution.
For advertising campaigns that require more detail, 3840×2160 4K resolution is available as an option.
Brightness ranges from 200 to 500 cd/m². Different contrast ratio options are also available for various indoor environments.
The display uses 4mm tempered anti-glare glass. This provides a durable front surface for everyday commercial use.
Multiple Screen Sizes
The Digital Advertising Totem is available in several sizes:
- 32 inch
- 43 inch
- 50 inch
- 55 inch
- 65 inch
- 75 inch
This range allows businesses to select a suitable display size for compact advertising areas or larger public spaces.
Non-Touch and Interactive Options
The standard model is non-touch and focuses on digital advertising and content playback.
When customer interaction is required, infrared touch and capacitive touch are available as options.
Touch configurations can support product browsing, digital directories, interactive information, wayfinding, visitor services, and self-service applications.
Android and Windows Options
The standard configuration is supplied without an operating system. Android and Windows options are available for different project requirements.
The Android configuration uses RK3288 hardware with 2GB RAM and 8GB storage.
Windows configurations can use Intel Core i3, i5, or i7 processors. Memory options include 4GB and 8GB. Storage options include 128GB, 256GB, and 512GB.
Suitable Applications
- Airports: advertising, passenger information, and promotional campaigns
- Hotels: lobby advertising, events, and guest information
- Restaurants: promotions, digital menus, and brand content
- Cafes: special offers, menus, and product promotions
- Retail stores: product advertising and promotional campaigns
- Shopping malls: brand advertising and commercial promotions
- Hospitals: service information and announcements
- Banks: financial service promotions and customer information
- Corporate offices: company information and visitor communication
Key Features
- Floor-standing advertising totem design
- 32″, 43″, 50″, 55″, 65″, and 75″ screen sizes
- 1920×1080 Full HD standard resolution
- 3840×2160 4K optional resolution
- 200-500 cd/m² brightness
- 1200:1 / 4000:1 / 5000:1 contrast ratio options
- Free CMS System
- Non-touch standard configuration
- Infrared touch option
- Capacitive touch option
- Android and Windows options
- 4mm tempered anti-glare glass
- Coated aluminium frame
- WiFi and RJ45 connectivity
- 2×5W built-in speakers
- USB 2.0×2
Technical Specifications
| Panel | TFT LCD |
| Panel Size | 32″ / 43″ / 50″ / 55″ / 65″ / 75″ |
| Resolution | 1920×1080 Full HD Standard / 3840×2160 4K Optional |
| Brightness | 200-500 cd/m² |
| Contrast Ratio | 1200:1 / 4000:1 / 5000:1 |
| Display Color | 16.7M |
| Response Time | 8ms |
| Panel Brand | BOE, AUO, Innolux, CSOT, etc. |
| Viewing Angle | 89°/89° |
| Internal Storage | 2GB + 16GB |
| Touch | Non-Touch Standard / Infrared Touch Optional / Capacitive Touch Optional |
| Glass | 4mm Tempered Glass, Level 7 on Mohs Hardness Scale, Anti-Glare |
| Frame Material | Coated Aluminium |
| Operating System | Without OS Standard / Android Optional / Windows Optional |
| Android Option | RK3288 / 2GB RAM / 8GB Storage |
| Windows Option | Intel Core i3/i5/i7 / 4GB or 8GB Memory / 128GB, 256GB or 512GB Storage |
| Speaker | 2×5W |
| Internet | WiFi / RJ45 |
| Interface | USB 2.0×2 |
| Video Format | MPEG1 / MPEG2 / MPEG4 / ASP / WMV / AVI |
| Image Format | JPEG / BMP / TIFF / PNG / GIF |
| Audio Format | Wave / MP3 / WMA / AAC |
| Image Resolution | Supports 1080p, 720p, 480p and Multiple Resolutions |
| Power Supply | AC 100-240V, 50/60Hz |
| Overall Power Consumption | ≤220W |
| Standby Power Consumption | <1W |
| Operating Temperature | 0-50℃ |
| Storage Temperature | -20-60℃ |
| Operating Humidity | 0.85 |
| Storage Humidity | 0%-95% Non-Condensing |
| Accessories Included | 1×Power Cord, 1×User Manual, Remote Controller |
Digital Advertising Totem for Commercial Projects
Arotouch supplies Digital Advertising Totem displays for distributors, system integrators, advertising companies, retailers, hospitality businesses, and commercial projects.
The display can be configured according to the application. Customers can choose the screen size, resolution, panel brand, touch technology, and operating system.
For standard advertising, the non-touch version provides a simple digital display solution. For interactive projects, touch technology adds customer engagement and information access.
With multiple sizes, optional 4K resolution, flexible hardware configurations, and a Free CMS System, Arotouch Digital Advertising Totem provides a practical solution for modern indoor advertising.
